    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine

    Industrial fully automatic Ice Block Machine direct system block ice making machine

    Product Description
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine

    Direct System Block Ice Machine

    The direct refrigeration block ice machine adopts food-grade aluminum alloy plate as evaporator material, only though a water feeding valve, the water is filled into the ice cans automatically, no any chemical residues during ice making process. Block ice is kept far away from any pollution,
    especially produce high quality ice block, which is sanitary and suitable for eating purpose and cooling purpose. This direct block ice maker produces blocks in a few hours, which means that the space requirements are reduced considerably.
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine

    Working principle

    Yixing ICS direct system block ice machine adopts edge-leading refrigeration industry technology.
    1. After direct heat exchange between refrigerant and water, in 5 to 8 hours, water is frozen out into ice.
    2. By that time, PLC controls the machine automatically into ice doffing process.
    3. Direct system utilizes hot Freon to defrost ice; so the defrosting process is fast.
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine

    Block Ice Application

    a. Ice factory
    b. Fresh preservation
    c. Ice engraving
    d. Edible ice
    Aluminum evaporator adopts special technique to make sure the ice conforms to food grade standards. In other words, the ice can be directly consumed. Besides saving labor work and electricity consumption, its unique modular design saves much floor area than traditional brine system block ice machine.
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Direct System Block Ice Machine Specification
    Model
    Daily capacity
    Electricity consumption
    Install power
    operating weight
    Dimension (L*W*H) mm
    BYB-10D
    1T
    4.85kw
    6kw
    960kg
    1800*1200*2000
    BYB-30D
    3T
    11.52kw
    14kw
    2180kg
    3600*1400*2200
    BYB-50D
    5T
    20.9kw
    25kw
    4280kg
    6200*2000*2250
    BYB-100D
    10T
    33.98kw
    50kw
    8070kg
    9800*2000*2410
    BYB-150D
    15T
    59.15kw
    75kw
    11860kg
    13500*2200*2565
    Detailed Images
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Main features
    1) The evaporator adopts special aluminum alloy plate which is more durable and meets food hygiene requirements.
    2) Ice thawing and ice doffing are fully automatic therefore no manual work is needed; 1 person is enough.
    3) The ice is doffed by batch and the whole ice doffing process only takes 25 minutes.
    4) The whole batch ice blocks can be moved by forklift, or designed with ice moving out device, quick and convenient.
    Forklift Ice Moving Device
    Original "mobile ice holding plate design", shovel whole ice holding plate out with forklift, each process takes about 3 minutes,
    saving 90% labor and time to a great extent, highest degree of automation.
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Hydraulic System+Wire Rope Hoisting
    Advantages of hydraulic system:

    *Save more space
    *Lower noise
    *Long service life
    *Small friction
    *Good balance
    Automatic characters
    *Add water automatically

    *Make ice automatically

    *Doff ice automatically

    *Move ice automatically
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Related Products
    Certificate
    CE
    M.2019.206.C0141
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Packing&Shipping

    Standard export packing

    Wood cases in standard container or less than container load
    Each set is wrapped in plywood case and transport in standard container
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Our Services

    Pre-Sales Service

    * Inquiry and consulting support.
    * Sample testing support.
    * View our Factory.

    After-Sales Service

    * Training how to install the machine, training how to use the machine.
    * Engineers available to service machinery overseas
    Company Introduction
    20 Ton Automatic Ice Block Machine , Restaurant Ice Machine
    Yixing city Ice Source Refrigeration Equipment Limited is a comprehensive modern manufacture of all kinds ice making plants, cold-room, high-efficiency cold air blower, energy-saving evaporative condenser, aluminum alloy pipe row and various civil constructions, combined with cold room engineering.

    ICS is located in Yixing, Wuxi, Jiangsu, CHINA. With over 20 year's successful experience in Chinese market, we focus on the technical innovation to improve the machine quality and strengthen innovation ability. By insisting on the spirit "unity, seeking truth, pioneering and dedication", we commit ourselves to research and development of new technology, striving to create a comprehensive refrigeration enterprise in China
